Gibson Custom 1963 Firebird V Vintage Sunburst
The Gibson 1963 Firebird V in Vintage Sunburst revolutionized electric guitar design with its sleek, offset body and neck-through construction. Crafted with input from automotive designer Ray Dietrich, this iconic model became a favorite for its striking looks and innovative features. The mahogany wings and nine-ply mahogany/walnut neck-through build deliver exceptional sustain, while the bound rosewood fingerboard and trapezoid inlays provide a touch of elegance.
Equipped with vintage-style mini-humbuckers, the Firebird V produces a bright, punchy tone with plenty of bite, perfect for both rhythm and lead work. From its reverse headstock to the period-correct hardware, this Gibson Custom Shop reissue captures the essence of the original, offering a playing experience that is as timeless as its design.
Guitar Specs
Body Style: Firebird
Body Shape: Designer
Body Material: Layered Mahogany
Binding: Fingerboard 1-Ply Cream
Body Finish: Nitrocellulose VOS (Vintage Patina)
Weight Relief: None
Profile: Traditional 1960s SlimTaper™ C Profile
Scale Length: 628.65 mm / 24.75 in
Fingerboard Material: Indian Rosewood
Fingerboard Radius: 304.8 mm / 12 in
Neck Material: 9-ply Mahogany/Walnut Neck-Through
Fret Count: 22
Frets: Authentic Medium-Jumbo
Nut Material: Nylon
Nut Width: 42.85 mm / 1.687 in
End Of Board Width: 56.89 mm / 2.239 in
Inlays: Aged Cellulose Nitrate Trapezoid
Joint: Neck-Through Construction
Finish: Nickel
Bridge: ABR-1
Saddle Material: Nickel-plated Brass
Tailpiece: Maestro Vibrola
Tuning Machines: Deluxe Banjo Tuners
Pickguard: 3-Ply White/Black/White Firebird Hot-stamped
Truss Rod: 2-way Adjustable
Truss Rod Cover: Black 1-Ply Gibson Hot-stamped
Control Knobs: Gold Top Hats w/ Silver Inserts
Switch Tip: Cream
Control Covers: Black
Strap Buttons: Aluminum
Pickup Covers: Nickel
Neck Pickup: Firebird Alnico V
Bridge Pickup: Firebird Alnico V
Controls: 2 500K CTS Volume Pots, 2 500K CTS Tone Pots, Hand-Wired Harness
Pickup Selector: 3-Way Switchcraft
Output Jack: Switchcraft
Strings Gauge: .010, .013, .017, .026, .036, .046
Case: Black/Yellow Custom Shop Hardshell
Accessories: Certificate of Authenticity
